MDF Deep Pleat

MDF (Medium Density Fibreboard) Deep pleat HEPA filters are used for removal of airborne contaminants, including fine dust, smoke, soot and microorganisms.

  • High efficiency micro glass fibre filter media
  • frame with MDF
Category:
EN1822 Width (mm) Height (mm) Depth (mm) Initial Pressure Drop (Pa) Air Flow (m3/hr)
H13 305 305 150 220 210
H13 305 610 150 220 420
H13 610 305 150 220 420
H13 610 610 150 220 850
H13 915 610 150 220 1500
H13 1220 610 150 220 2000
H13 305 305 292 220 420
H13 305 610 292 220 850
H13 610 305 292 220 850
H13 610 610 292 220 1700
H14 305 305 150 250 210
H14 305 610 150 250 420
H14 610 305 150 250 420
H14 610 610 150 250 850
H14 915 610 150 250 1500
H14 1220 610 150 250 2000
H14 305 305 292 250 420
H14 305 610 292 250 850
H14 610 305 292 250 850
H14 610 610 292 250 1700
