Pleated Dust Collection Cartridges

Pleated spun bonded polyester the filter media is placed in a cylindrical configuration with the support of a metal core & encapsulated with a metal end caps to form a pleated dust collection cartridge. The end caps are configured to mount as clean side or dirt side fitment. In the case of a metal caps these cartridges are supported with soft sponge rubber sealing to ensure positive sealing of the filter while fitment.

Category: Industrial Air filtration

Description

Tehnical SpecificationsFilter media

Spun Bonded Polyester Media

Area weight of filter media

170 gms/m²
200 gms/m²
260 gms/m²

Coating

PTFE coating for oil & moisture removal.
Aluminum coating for antistatic application.
Stainless steel coating for antistatic application.
Fire retardant coating.
PTFE lamination for very stick dust.

SizesFitment configuration

Clean Side Fitment (Model: 2 & 3)
Dirt Side Fitment (Model : 1)

Filtration area

0.96 m² to 20.0 m²

Application

Sr. No.	Diameter Of element	Length Of filter Element
1	150 mm	500 mm
2	150 mm	1000 mm
3	150 mm	1400 mm
4	150 mm	2000 mm
5	225 mm	500 mm
6	225 mm	1000 mm
7	225 mm	1400 mm
8	225 mm	2000 mm
9	325 mm	300 mm
10	325 mm	500 mm
11	325 mm	606 mm
12	325 mm	1000 mm
13	325 mm	1400 mm
