Spectra Guard HT HEPA HF 250

Spectrum high-temperature HEPA filters are used for filtration applications involving temperatures greater than 100°C and up to 390°C. They are mostly used in nuclear plants & food industry ovens. Filter with higher media area allows larger airflow along with high particle efficiency.

  • Rugged design
  • high media area and higher air volume. Tested and scanned as per EN 1822. Available from E10-H14 grade. High mechanical strength.
Category:
EN1822 Width (mm) Height (mm) Depth (mm) Initial Pressure Drop (Pa) Air Flow (m3/hr)
H13 305 305 150 250 240
H13 305 610 150 250 490
H13 610 305 150 250 490
H13 610 610 150 250 980
H13 915 610 150 250 1500
H13 1220 610 150 250 2000
H13 305 305 292 250 490
H13 305 610 292 250 980
H13 610 305 292 250 980
H13 610 610 292 250 1960
H14 305 305 150 250 210
H14 305 610 150 250 430
H14 610 305 150 250 430
H14 610 610 150 250 850
H14 915 610 150 250 1300
H14 1220 610 150 250 1740
H14 305 305 292 250 430
H14 305 610 292 250 850
H14 610 305 292 250 850
H14 610 610 292 250 1700
